DAP Server help & support

Current version: 2026.1

Latest Download

Support topics

Support requests

System requirements

DAP server release notes

DAP

DAP Server 2026.1
This update is for customers with a maintenance subscription.

Help and Support

Help

Software downloads

Get the latest versions of all Seequent tools and software.

Download the latest software

Seequent ID and account management

Use your Seequent ID to access your solutions, manage your info, and update security options.

Learn more about Seequent ID

Subscriptions, licenses and billing

Manage your licenses, seat and users, or update your payment details.

Learn about product subscriptions

IT administrators

If you need to know information relating to server requirements, network details and more.

Learn more about IT administration requirements

Product help

Find answers to your technical questions with our in-depth product help information.

Visit product help

Support

Seequent Learning

Get started fast or upskill whilst working with our onboarding and advanced free eLearning courses.

Visit Seequent Learning

Knowledge Base

Access an online knowledge base of FAQs and support articles or contact support by signing in to MySeequent.

Visit Knowledge Base

Seequent Community

Discover new opportunities, connect with peers, and share insights and best practices with others in your field.

Learn more at Seequent Community

Support requests

Managing your support requests

Here at Seequent we are committed to seeing the possibilities and anticipating what is next. As such, we are continuously evolving to better serve you. You can now actively monitor and manage your support request via MySeequent using your unique Seequent ID.

Submit a support request

Read the requirements for end users who use Seequent products on their desktops/laptops.

You can get links to the latest versions of Seequent products & tools here.

A Geosoft DAP Server should be dedicated to providing Geosoft DAP services only in order to provide the required performance and responses to requests from data users. The minimum recommended DAP Server configuration for a corporate DAP solution is:

DAP Server requirements

	Minimum	Recommended
Operating system	Windows Server 2022, 2019, 2016, 2012 R2	Windows Server 2025
Web server	Microsoft IIS 8.5	Microsoft IIS 10
Database	Microsoft SQL Server 2012, 2014, 2016, 2017, 2019, 2022	Microsoft SQL Server 2025
Memory	8GB	32GB
CPU	Virtual Machine with 8 CPU
Disk space ₁	50GB for operating system	100 GB for operating system; 500 GB–2 TB for datasets and DAP temporary files
Other applications	Microsoft .NET Framework 8.0; Apache HTTPS Server 2.4.63; Django Web Framework 5.1.14	Microsoft .Net Framework 8.0, Apache HTTPS Server 2.4.63, Django Web framework 5.1.14
Third party support	ArcGIS Server ₂ 10.9.1; acQuire 4.6.2.2	ArcGIS Server ₂ 10.9.1; acQuire 4.6.2.2
Browser ₃	Microsoft Edge; Google Chrome	Microsoft Edge; Google Chrome

Notes
① Actual physical disk space requirements for datasets and temporary files depend on the client’s configuration and data serving requirements.

② ArcGIS Server is required when managing ESRI file geodatabases, LYR files and raster images. GDP currently supports ArcGIS v10,11,12.

③ Applies to DAP Administrator.

Metadata editor requirements

	Minimum	Recommended
Operating system	Windows Server 2022, 2019, 2016, 2012 R2	Windows Server 2025
Database	Microsoft SQL Server 2012, 2014, 2016, 2017, 2019, 2022	Microsoft SQL Server 2025
Other applications	Microsoft .NET Framework 8.0; Apache HTTPS Server 2.4.63; Django Web Framework 5.1.14	Microsoft .NET Framework 8.0; Apache HTTPS Server 2.4.63; Django Web Framework 5.1.14
Browser	Microsoft Edge, Google Chrome	Microsoft Edge, Google Chrome

Geosoft DAP Server is able to efficiently catalog and deliver a broad range of dataset types, including very large geospatial grids, 3D voxels, images and vector data. In addition to inherently spatial dataset types other formats, such as Adobe PDF, ZIP, and other non-spatial file formats, are supported as Documents.

Below is a summary of supported data types in DAP Server and support of DAP data services and features for each dataset type.

You can get links to the latest versions of Seequent products & tools here.

Search, view metadata, preview data

Grids including Geosoft GRD, HyperGrid, ERMapper ERS and other supported grid types.
Images including GeoTIFF, ECW, JPG and JPEG 2000, and other supported image formats
Voxels
Sections as oriented grids and images
Geosoft Databases and HXYZ point files
Geosoft Drillhole Projects
Geosoft Maps and 3D Views (3DV)
Geosoft 3D files including geostring and geosurface files
Geosoft Offline Datasets
VOXI Models
GM-SYS 3D Models
MapInfo TAB files
Esri Shapefiles
Esri Layer files (Requires Esri integration extension)
Esri Map Services
Documents and non-spatial file formats including PDF and ZIP
RDBMS (Relational Database Management System) including SQL, Access, and Oracle
acQuire PointSample and Collar (Requires acQuire integration extension)

Download

Grids including Geosoft GRD, HyperGrid, ERMapper ERS and other supported grid types.
Images including GeoTIFF, ECW, JPG and JPEG 2000, and other supported image formats
Voxels (Not supported by MapInfo DAP client tool)
Sections as oriented grids and images
Geosoft Databases and HXYZ point files
Geosoft Drillhole Projects
Geosoft Maps and 3D Views (3DV)
Geosoft 3D files including geostring and geosurface files
VOXI Models
GM-SYS 3D Models
MapInfo TAB files
Esri Shapefiles
Esri Layer files (Requires Esri integration extension, Not supported by MapInfo DAP client tool)
Esri Map Services (Not supported in Flamingo Web Client and DAP XML, Download as image only)
Documents and non-spatial file formats including PDF and ZIP
RDBMS (Relational Database Management System) including SQL, Access, and Oracle
acQuire PointSample and Collar (Requires acQuire integration extension)

Window

Grids including Geosoft GRD, HyperGrid, ERMapper ERS and other supported grid types.
Images including GeoTIFF, ECW, JPG and JPEG 2000, and other supported image formats
Voxels
Geosoft Databases and HXYZ point files
Geosoft Drillhole Projects
MapInfo TAB files
Esri Shapefiles
Esri Layer files (Requires Esri integration extension)
Esri Map Services
RDBMS (Relational Database Management System) including SQL, Access, and Oracle
acQuire PointSample and Collar (Requires acQuire integration extension)

Reformat

Grids including Geosoft GRD, HyperGrid, ERMapper ERS and other supported grid types.
Images including GeoTIFF, ECW, JPG and JPEG 2000, and other supported image formats
Sections as oriented grids and images
MapInfo TAB files
Esri Shapefiles
Esri Map Services

Resample

Grids including Geosoft GRD, HyperGrid, ERMapper ERS and other supported grid types.
Images including GeoTIFF, ECW, JPG and JPEG 2000, and other supported image formats
Voxels
Sections as oriented grids and images
Esri Map Services

Reproject

Grids including Geosoft GRD, HyperGrid, ERMapper ERS and other supported grid types.
Images including GeoTIFF, ECW, JPG and JPEG 2000, and other supported image formats
MapInfo TAB files
Esri Shapefiles
Esri Layer files (Requires Esri integration extension)
Esri Map Services
RDBMS (Relational Database Management System) including SQL, Access, and Oracle
